Precision Multi-Hole Drive Base & Flange
Discover top-quality custom Precision Multi-Hole Drive Base & Flange from KGL Machining, a leading Manufacturer and Supplier based in China.
General Industrial Components
Modern automated transmission systems require joint components that can withstand multi-directional torque and high-frequency vibrations. This Precision Multi-Hole Drive Base & Flange serves as a critical structural pivot requiring high positional accuracy and perfect coaxiality with the rotationa
Or email drawings to kgl@kglmfc.com
Key Specifications
| Parameter | KGL Capability |
|---|---|
| Parameter | Specification Details |
| Component Name | Precision Multi-Hole Drive Base & Flange |
| Common Materials | Aerospace-grade Aluminum (7075-T6), Alloy Steel, Stainless Steel, Titanium |
| Surface Treatment | Matte Anodized Black / Ultra-fine Sandblasted Electroless Nickel Plating |
| Core Tolerances | True position of indexing holes within 0.005mm |
| Finishing Details | Full CNC automatic chamfering; meticulous manual micro-deburring and ultrasonic cleaning |
| Tolerance | ±0.005 mm standard on metals, engineering plastics, and carbon fiber composite |
| Process | 5-axis CNC milling, 3+2 milling, CNC turning, EDM as required |
| Inspection | Hexagon / Zeiss CMM with 0.0015 mm accuracy, full first-article reports |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Capacity | 100+ CNC machines including 11 five-axis centers |
| MOQ | No MOQ; 1-piece prototypes supported |
| Quote | Within 24 hours for complete 2D/3D files |
About This Part
Modern automated transmission systems require joint components that can withstand multi-directional torque and high-frequency vibrations. This Precision Multi-Hole Drive Base & Flange serves as a critical structural pivot requiring high positional accuracy and perfect coaxiality with the rotational center. At KGL, we eliminate the "micron-level error amplification effect" using high-rigidity CNC machining and advanced turn-mill techniques. This ensures that every Precision Multi-Hole Drive Base & Flange satisfies strict industrial assembly standards, guaranteeing smooth power transmission. Core Technical Specifications Parameter Specification Details Component Name Precision Multi-Hole Drive Base & Flange Common Materials Aerospace-grade Aluminum (7075-T6), Alloy Steel, Stainless Steel, Titanium Surface Treatment Matte Anodized Black / Ultra-fine Sandblasted Electroless Nickel Plating Core Tolerances True position of indexing holes within 0.005mm Finishing Details Full CNC automatic chamfering; meticulous manual micro-deburring and ultrasonic cleaning KGL Manufacturing Advantages One-Setup Indexing: KGL machines the hole patterns, positioning steps, and central bore in a single setup, completely eliminating cumulative indexing tolerances. Ultra-Precise Spigot Control: We enforce strict standards for cylindricity and perpendicularity (IT5-IT6), preventing centerline misalignme
Why Machine It at KGL
Five-Axis Fleet
100+ CNC machines including 11 five-axis centers run complex geometry in single setups, so tolerances do not stack up across refixturing.
Verified Accuracy
±0.005 mm standard on metals, plastics, and carbon fiber composite, verified on Hexagon and Zeiss CMMs (0.0015 mm accuracy).
Fast Prototypes
Engineering feedback with every quotation; prototype parts typically machined in 15 to 25 days.
One Supplier, End to End
Material sourcing, machining, heat treatment coordination, finishing, CMM inspection and export packaging under one roof.
Commercial Terms
| Commercial | Detail |
|---|---|
| MOQ | No MOQ |
| Quote turnaround | 24 hours for complete 2D/3D files |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Standard tolerance | ±0.005 mm |
| Precision tolerance | ±0.005 mm on critical features |
| Inspection | Hexagon / Zeiss CMM + first-article reports |
Common Questions
Which materials can this part be machined from?
Common options include Aluminum alloys, stainless steels, brass, copper, titanium and engineering plastics; the exact grade follows your drawing. Send your drawing and we confirm material availability and stock within 24 hours.
What tolerances can you hold?
Standard tolerance is ±0.005 mm on metals, engineering plastics, and carbon fiber composite. Every dimension is verified against the 3D model on Hexagon or Zeiss CMMs.
How fast can I get first samples?
You receive engineering feedback with the quotation, within 24 hours of sending a drawing. Prototype parts are typically machined in 15 to 25 days depending on geometry and finishing.
What quality documentation comes with the parts?
Each shipment can include a first-article inspection report, dimensional CMM report, and material certificates. KGL is certified to ISO 9001:2015, ISO 13485:2016 and AS9100D.
Is there a minimum order quantity?
No. KGL supports 1-piece prototypes through volume production on 100+ CNC machines, so you can start small and scale the same process.
