Precision Valve Ring Nozzle
Discover top-quality custom Precision Valve Ring Nozzle from KGL Machining, a leading Manufacturer and Supplier based in China. As a trusted Factory, we
General Industrial Components
This valve ring nozzle is designed for use in industrial fluid systems and welded piping. It’s machined to the Unified Thread CLASS 2 spec, with a 0.5mm chamfer on every edge, inside and out.
Or email drawings to kgl@kglmfc.com
Key Specifications
| Parameter | KGL Capability |
|---|---|
| Specification Item | Specification Details |
| Product Name | Valve Ring Nozzle |
| Material | POM |
| Thread Standard | Uniform Thread, Class 2 Accuracy |
| Angle Tolerance | ±0.5° |
| Fractional Dimension Tolerance | ±1/32" |
| Surface Finish | 32RA |
| Chamfering Requirements | 0.5mm chamfer on all inner and outer edges |
| Welding Standard | AWS D18.1/D18.1M |
| Tolerance | ±0.005 mm standard on metals, engineering plastics, and carbon fiber composite |
| Process | 5-axis CNC milling, 3+2 milling, CNC turning, EDM as required |
| Inspection | Hexagon / Zeiss CMM with 0.0015 mm accuracy, full first-article reports |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Capacity | 100+ CNC machines including 11 five-axis centers |
| MOQ | No MOQ; 1-piece prototypes supported |
| Quote | Within 24 hours for complete 2D/3D files |
About This Part
This valve ring nozzle is designed for use in industrial fluid systems and welded piping. It’s machined to the Unified Thread CLASS 2 spec, with a 0.5mm chamfer on every edge, inside and out. Surface finish is held to 32RA, so assembly is smooth and sealing is consistent. We make it from POM for good wear resistance, chemical stability, and dimensional consistency over time. With years of experience in precision machining, we build these nozzles to meet AWS D18.1/D18.1M welding standards, and they’re easy to install and maintain across a range of valve and piping setups. Here are the specs at a glance: Product Specifications Specification Item Specification Details Product Name Valve Ring Nozzle Material POM Thread Standard Uniform Thread, Class 2 Accuracy Angle Tolerance ±0.5° Fractional Dimension Tolerance ±1/32" Surface Finish 32RA Chamfering Requirements 0.5mm chamfer on all inner and outer edges Welding Standard AWS D18.1/D18.1M What sets our valve ring nozzle apart is the level of control we maintain over every dimension. We use a graded tolerance system that keeps things consistent: Angular tolerance of ±0.5° and dimensional tolerance of ±0.010" mean the nozzle fits the mating parts precisely, which helps cut down on leaks and keeps the system running smoothly. POM is a solid choice here. It’s self-lubricating and handles repeated cycling well, so parts last longer eve
