M24 x 0.5 Fine Pitch Lock Nut in 7075-T6, Face Runout 0.01
7075-T6 lock nut M24 x 0.5 6H: Ø25.5 and Ø31 +/-0.05 diameters, 14.5 +/-0.05 length, 60 degree locating slot, face runout 0.01 A, black anodized. Quote in 24 hours.
Robotics & Humanoid Robots
A fine pitch locking nut for encoder and motor shafts, turned complete from 7075-T6 with a 60 degree slot and a verified face runout for bearing and encoder seating.
Or email drawings to kgl@kglmfc.com
Key Specifications
| Parameter | KGL Capability |
|---|---|
| Material | Aluminum 7075-T6, 0.02 kg |
| Process | CNC turning of OD and faces, M24 x 0.5 6H internal threading, 60 degree slot turning, deburring, black anodize |
| Thread | M24 x 0.5-6H |
| Diameters | Ø25.5 +/-0.05, Ø31 +/-0.05 |
| Length | 14.5 +/-0.05 |
| Runout | Face Ø0.01 A |
| Inspection | M24 x 0.5-6H plug gauge, micrometer and CMM on runout, appearance |
| Tolerance | ±0.005 mm standard on metals, engineering plastics, and carbon fiber composite |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Capacity | 100+ CNC machines including 11 five-axis centers |
| MOQ | No MOQ; 1-piece prototypes supported |
| Quote | Within 24 hours for complete 2D/3D files |
About This Part
Fine pitch M24 x 0.5 threads are what let a lock nut clamp precisely without whipping past the shoulder. This nut runs the thread at 6H class, plug gauged, with Ø25.5 and Ø31 plus or minus 0.05 diameters, 14.5 plus or minus 0.05 length, and a 60 degree locating slot that indexes against the mating part.
Face runout is held at 0.01 A, which is the number that decides whether the nut seats square on the bearing or encoder face. 7075-T6 keeps the nut strong at 0.02 kg, and black anodize handles wear and appearance with the thread class protected.
Inspection is the M24 x 0.5 6H plug gauge, micrometer and CMM on face runout, and appearance.
This part family supports the Robotics Parts industry. Read how KGL machines parts for that sector, then send your drawing for a quote.
Why Machine It at KGL
Five-Axis Fleet
100+ CNC machines including 11 five-axis centers run complex geometry in single setups, so tolerances do not stack up across refixturing.
Verified Accuracy
±0.005 mm standard on metals, plastics, and carbon fiber composite, verified on Hexagon and Zeiss CMMs (0.0015 mm accuracy).
Fast Prototypes
Engineering feedback with every quotation; prototype parts typically machined in 15 to 25 days.
One Supplier, End to End
Material sourcing, machining, heat treatment coordination, finishing, CMM inspection and export packaging under one roof.
Part-Specific Advantages
- M24 x 0.5 6H fine pitch thread, plug gauged
- Face runout 0.01 A for square seating
- 60 degree locating slot
- Ø25.5 and Ø31 +/-0.05, 14.5 +/-0.05 long
- 7075-T6 at 0.02 kg, black anodized
Typical Applications
- Encoder and motor shaft lock nuts
- Bearing preload nuts in automation assemblies
- Precision round nuts with locating slots
Commercial Terms
| Commercial | Detail |
|---|---|
| MOQ | No MOQ; 1-piece prototype supported |
| Quote | Within 24 hours for complete 2D/3D files |
| Terms | EXW / FOB Shenzhen |
| Certifications | ISO 9001:2015 |
| Packaging | Individual bubble wrap, export carton or wooden case |
| Lead Time | Prototypes 7 to 15 days; production scheduled by volume |
Common Questions
Why 0.5 pitch instead of standard M24?
Fine pitch gives finer axial adjustment per turn and resists loosening under vibration, which is exactly what a lock nut on an encoder stack is for.
What does 0.01 face runout buy?
A nut that seats square. Tilted lock nuts preload bearings unevenly and walk loose; the runout callout is the prevention.
