Custom Optical Lens Mount in 6061-T6, Hard Anodized and Bead Blasted, Critical Dims 100 Percent Checked

Custom 6061-T6 optical lens mount, 55.12 +/-0.04 by 29.64 +/-0.05 by 13.22 +/-0.05 mm, M11 x P0.5 fine clean thread for lens engagement, 2x M2 fasteners, 4x 5.7 mm counterbores at 90 degrees, hard anodized matte black finish. Quote in 24 hours.

Custom Optical Lens Mount, 6061-T6 with M11 x P0.5 Fine Thread

Semiconductor & Optics

A compact custom lens mount machined from 6061-T6: an M11 x P0.5 fine thread that positions the optic without play, tight +/-0.04 mm body dimensions, and a bead blasted hard anodize in matte black.

Custom to drawing±0.005 mm standard toleranceQuote in 24 hNo MOQISO 9001 · ISO 13485 · AS9100D

Request a Quote for This Part

Or email drawings to kgl@kglmfc.com

Relevant Capabilities

CNC Milling

Materials

Aluminum

Key Specifications

Parameter	KGL Capability
Material	Aluminum 6061-T6
Body dimensions	55.12 +/-0.04 x 29.64 +/-0.05 x 13.22 +/-0.05 mm
Optic thread	M11 x P0.5, clean light fit
Fasteners	2x M2 with spring washers; 4x 2.0 mm and 2.7 mm holes
Counterbores	4x 5.7 mm at 90 degree spacing
Controlled feature	0.338 +/-0.03 mm per drawing
General tolerance	ISO 2768-m per drawing
Finish	Hard anodized, bead blasted, matte black
Surface standard	Burr free, no scratches or impact marks
Process	CNC milling, drilling and tapping, fine thread cutting, deburring, hard anodize with bead blast, final precision machining
Inspection	Caliper and micrometer on dimensions, thread gauges on M11 and M2, CMM 100 percent on star-marked critical dimensions
Tolerance	±0.005 mm standard on metals, engineering plastics, and carbon fiber composite
Certifications	ISO 9001:2015, ISO 13485:2016, AS9100D
Capacity	100+ CNC machines including 11 five-axis centers
MOQ	No MOQ; 1-piece prototypes supported
Quote	Within 24 hours for complete 2D/3D files

About This Part

This is a custom lens mount for an optical instrument assembly, and the fine thread is its centerpiece. The M11 x P0.5 clean light thread is cut so a mating lens cell screws in with even, minimal play; coarse threads rock the optic, and a pitch of 0.5 mm turns positioning into a fine adjustment. The thread is gauged, not eyeballed, on every part.

The body dimensions are held to drawing bands of 55.12 +/-0.04, 29.64 +/-0.05 and 13.22 +/-0.05 mm, with the drawing's star-marked dimensions treated as critical controls and inspected one hundred percent. Fastening runs through 2x M2 threads with spring washers, four 2.0 mm holes, a 2.7 mm hole and a 4x 5.7 mm counterbore pattern at 90 degree spacing. One more sub millimeter callout, 0.338 +/-0.03 mm, is held on the same drawing and inspected with the critical set. General tolerances follow the drawing's ISO 2768-m class note.

The finish is a two step system: hard anodize for a wear resistant surface, bead blasted for a uniform matte black texture that scatters stray light and resists showing scratches. Finishing follows final machining so the precise surfaces stay precise; thread and critical dimensions are re-gauged after coating.

Surface standard is explicit, because optical hardware shows every flaw: parts ship clean, burr free, with no scratches or impact marks, and star-marked critical dimensions are verified on the CMM part by part with thread gauges on the M11 and M2 features.
