High-Precision Connector Body for Optoelectronic Communication
Discover top-quality custom High-Precision Connector Body for Optoelectronic Communication from KGL Machining, a leading Manufacturer and Supplier based in
Semiconductor & Optics
1. Functions & Applications Sub-Micron Alignment: Provides a highly stable physical channel for fiber ferrules, ensuring perfect alignment.
Or email drawings to kgl@kglmfc.com
Key Specifications
| Parameter | KGL Capability |
|---|---|
| Specification Item | Detailed Capabilities Quality Standards |
| Typical Materials | SUS304, SUS316, AL6061, AL7075, POM-C Material Test Certificate (MTC) |
| Surface Treatment | Black Anodizing (MIL-A-8625), Passivation Salt spray & thickness verification |
| Tolerances | General: ISO 2768-f | Critical: up to $$\pm 0.005\text{mm$ CMM & Optical Projector 100% check |
| Cosmetic Standard | Defect-free, zero burrs, zero tool marks 30× Microscope visual inspection |
| Laser Marking | Min. height 1.5mm, high-contrast black fill Vision system automated verification |
| Tolerance | ±0.005 mm standard on metals, engineering plastics, and carbon fiber composite |
| Process | 5-axis CNC milling, 3+2 milling, CNC turning, EDM as required |
| Inspection | Hexagon / Zeiss CMM with 0.0015 mm accuracy, full first-article reports |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Capacity | 100+ CNC machines including 11 five-axis centers |
| MOQ | No MOQ; 1-piece prototypes supported |
| Quote | Within 24 hours for complete 2D/3D files |
About This Part
1. Functions & Applications Sub-Micron Alignment: Provides a highly stable physical channel for fiber ferrules, ensuring perfect alignment. High-Density Feature Integration: Combines threads, stepped counterbores, and precision angled facets within a compact footprint. Strong Protection: Machined from high-performance materials to withstand frequent mating cycles and thermal fluctuations. 2. Core Manufacturing Advantages Micro Deburring & Ultrasonic Cleaning: 100% inspection under 30× magnification paired with multi-stage ultrasonic cleaning to eliminate microscopic particulates. Precision Hardware Integration: Expert capability in secondary assembly, such as precision press-fitting of locating pins High-Contrast Laser Marking: Ultra-fine engraving (character height $\ge 1.5\text{mm}$, depth ~0.02mm) with black filling for permanent traceability. Advanced 5-Axis Machining: Single-setup machining for complex multi-sided features and APC inclined surfaces to eliminate cumulative errors. 3. Technical Specifications Specification Item Detailed Capabilities Quality Standards Typical Materials SUS304, SUS316, AL6061, AL7075, POM-C Material Test Certificate (MTC) Surface Treatment Black Anodizing (MIL-A-8625), Passivation Salt spray & thickness verification Tolerances General: ISO 2768-f | Critical: up to $$\pm 0.005\text{mm$ CMM & Optical Projector 100% check Cosmetic Standard Defe
Why Machine It at KGL
Five-Axis Fleet
100+ CNC machines including 11 five-axis centers run complex geometry in single setups, so tolerances do not stack up across refixturing.
Verified Accuracy
±0.005 mm standard on metals, plastics, and carbon fiber composite, verified on Hexagon and Zeiss CMMs (0.0015 mm accuracy).
Fast Prototypes
Engineering feedback with every quotation; prototype parts typically machined in 15 to 25 days.
One Supplier, End to End
Material sourcing, machining, heat treatment coordination, finishing, CMM inspection and export packaging under one roof.
Commercial Terms
| Commercial | Detail |
|---|---|
| MOQ | No MOQ |
| Quote turnaround | 24 hours for complete 2D/3D files |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Standard tolerance | ±0.005 mm |
| Precision tolerance | ±0.005 mm on critical features |
| Inspection | Hexagon / Zeiss CMM + first-article reports |
Common Questions
Which materials can this part be machined from?
Common options include 6061/7075 aluminum, stainless steel 316/304, brass and engineering plastics such as PEEK and POM. Send your drawing and we confirm material availability and stock within 24 hours.
What tolerances can you hold?
Standard tolerance is ±0.005 mm on metals, engineering plastics, and carbon fiber composite. Every dimension is verified against the 3D model on Hexagon or Zeiss CMMs.
How fast can I get first samples?
You receive engineering feedback with the quotation, within 24 hours of sending a drawing. Prototype parts are typically machined in 15 to 25 days depending on geometry and finishing.
What quality documentation comes with the parts?
Each shipment can include a first-article inspection report, dimensional CMM report, and material certificates. KGL is certified to ISO 9001:2015, ISO 13485:2016 and AS9100D.
Is there a minimum order quantity?
No. KGL supports 1-piece prototypes through volume production on 100+ CNC machines, so you can start small and scale the same process.
