KGL machines precision brass flow control adapters from C3604 / H59-1 bar in a single turn-mill setup: thread, seal groove, and center orifice cut in one clamping, coaxiality 0.008 mm, orifice tolerance plus or minus 0.005 mm, every adapter leak tested before shipment.

Custom to drawing±0.005 mm standard toleranceQuote in 24 hNo MOQISO 9001 · ISO 13485 · AS9100D

Request a Quote for This Part

Or email drawings to kgl@kglmfc.com

Relevant Capabilities

Turn-Mill Machining CNC Turning

Materials

Brass & Copper Alloys Surface Treatment/Passivation

Key Specifications

Parameter	KGL Capability
Material	Free-cutting brass C3604 / H59-1 / HPb59-1, RoHS compliant
Condition	Machined finish, stress relieved
Process	Swiss turning / turn-mill in one setup; step turning; thread and seal groove cutting; center orifice and nozzle steps; ultrasonic cleaning; passivation or anti-oxidation
Size	Per drawing, typically 15 to 35 mm outer diameter
Coaxiality	0.008 mm max on steps and threads
Orifice Tolerance	Plus or minus 0.005 mm on center throttle bore
Surface Roughness	Ra 0.8 to 1.6 um; Ra 0.4 on sealing steps and journals
Standard Tolerance	Plus or minus 0.005 mm on machined features
Inspection	Leak test, thread go / no-go gauges, vision measuring system or tool microscope
MOQ	No MOQ; 1-piece prototypes supported
Tolerance	±0.005 mm standard on metals, engineering plastics, and carbon fiber composite
Certifications	ISO 9001:2015, ISO 13485:2016, AS9100D
Capacity	100+ CNC machines including 11 five-axis centers
Quote	Within 24 hours for complete 2D/3D files

About This Part

The flow control adapter meters gas or liquid through a central orifice and a fine external thread seat. It looks simple on a drawing and punishes loose process control in service: if the thread, the seal groove, and the orifice do not run true to a common axis, the assembly weeps or hunts. KGL machines each adapter from free-cutting brass bar (C3604 / H59-1 / HPb59-1, RoHS compliant) chosen for clean chip formation and uniform, seal-ready surfaces.

The route is built around single-setup discipline. Swiss turning or turn-mill work completes the outer diameters and stepped shoulders in one clamping. The external thread and seal groove are cut next, still without moving the part, so runout between thread and shoulder stays inside 0.008 mm. The axial center orifice and nozzle steps are drilled and chamfered in the same setup, holding the orifice diameter to plus or minus 0.005 mm for repeatable throttling. After machining, every adapter is ultrasonic cleaned, then passivated or given an anti-oxidation treatment per drawing.

Adapters are leak tested with air under water or on a pressure decay bench, threads are checked with go and no-go gauges, and orifice and step dimensions are verified on a vision measuring system or tool microscope. Material certificates travel with each order. Send your drawing for DFM feedback and a quotation within 24 hours.
