304 Stainless Liquid Cooling Adapter, CNC Turned to ASME Y14.5
304 stainless liquid cooling adapter: 2.0 in OD, 0.88 in bore, 1.81 in long, welds to AWS D18.1, edges broken to 0.02 in, 100 percent inspected. Quote within 24 hours.
Semiconductor & Optics
A symmetrical 304 stainless cooling adapter turned from tube stock: 2.0 in outside diameter, 0.88 in bore, 1.81 in long, to ASME Y14.5 imperial callouts with AWS D18.1 welds and every edge broken to 0.02 in.
Or email drawings to kgl@kglmfc.com
Key Specifications
| Parameter | KGL Capability |
|---|---|
| Material | Stainless steel S/S 304 (ASTM A276 / 06Cr19Ni10) |
| Process | Tube stock CNC turning; edge breaking; inspection and cleaning |
| Key dimensions | OD 2.0 in; bore 0.88 in; length 1.81 in |
| Tolerance standard | ASME Y14.5-2009; angles ±0.5 deg; fractional ±1/32 in; X.X ±0.020 in; X.XX ±0.010 in; critical ±0.005 in |
| Surface finish | 63 Ra microinch general |
| Welding | AWS D18.1 / D18.1M:2009 where applicable |
| Edge condition | All internal and external edges broken to 0.02 in (0.5 mm) |
| Inspection | 100 percent size and appearance check after turning |
| Tolerance | ±0.005 mm standard on metals, engineering plastics, and carbon fiber composite |
| Certifications | ISO 9001:2015, ISO 13485:2016, AS9100D |
| Capacity | 100+ CNC machines including 11 five-axis centers |
| MOQ | No MOQ; 1-piece prototypes supported |
| Quote | Within 24 hours for complete 2D/3D files |
About This Part
Cooling loops reward smooth, concentric flow paths, and this adapter delivers one from a single tube blank. The 304 stainless tube is turned on a CNC lathe to a 2.0 in outside diameter with a 0.88 in bore and a 1.81 in overall length, keeping the flow path round and concentric so junction losses stay predictable.
The drawing follows ASME Y14.5-2009 in imperial units: decimal features at X.X ±0.020 in and X.XX ±0.010 in, angles at ±0.5 degrees, and 63 Ra microinch on general surfaces. Where the design joins tube sections, welds meet AWS D18.1, and every internal and external edge leaves the lathe broken to 0.02 in.
304 brings the corrosion resistance and clean surface that cooling and fluid equipment need, and each piece is fully inspected for size and appearance after turning before it is packed.
This part family supports the Semiconductor Parts industry. Read how KGL machines parts for that sector, then send your drawing for a quote.
Why Machine It at KGL
Five-Axis Fleet
100+ CNC machines including 11 five-axis centers run complex geometry in single setups, so tolerances do not stack up across refixturing.
Verified Accuracy
±0.005 mm standard on metals, plastics, and carbon fiber composite, verified on Hexagon and Zeiss CMMs (0.0015 mm accuracy).
Fast Prototypes
Engineering feedback with every quotation; prototype parts typically machined in 15 to 25 days.
One Supplier, End to End
Material sourcing, machining, heat treatment coordination, finishing, CMM inspection and export packaging under one roof.
Part-Specific Advantages
- Turned from 304 stainless tube in one lathe flow for a concentric flow path
- 2.0 in OD, 0.88 in bore, 1.81 in long, per ASME Y14.5 imperial callouts
- Welded joints to AWS D18.1 where the design requires
- All edges broken to 0.02 in for safe handling and clean assembly
- 63 Ra microinch general surface, bright 304 finish
- 100 percent size and appearance inspection before packing
Typical Applications
- Cooling loop adapters for semiconductor process equipment
- Fluid transfer connectors on analytical and laboratory instruments
- Plumbing interfaces on industrial water and coolant systems
Commercial Terms
| Commercial | Detail |
|---|---|
| MOQ | No MOQ; 1-piece prototype supported |
| Quote | Within 24 hours for complete 2D/3D files |
| Terms | EXW / FOB Shenzhen |
| Certifications | ISO 9001:2015 |
| Packaging | Individual bubble wrap, export carton or wooden case |
Common Questions
Is 304 the right grade for a cooling adapter?
For most water glycol and coolant loops, yes: 304 resists corrosion, cleans up bright, and costs less than 316. If your loop runs chlorides or aggressive chemistry, we will suggest 316 before you commit.
Can you hold the imperial callouts on a metric shop floor?
Yes. This lot was produced and inspected in inches against the ASME Y14.5 drawing, which is routine for export work.
Do you supply the welds or the bare adapter?
Both are possible. Quote from the drawing and we will include AWS D18.1 welding and inspection in the route where the design calls for it.
